- Place of Origin:Guangdong, China
- Brand Name:Chipskey
- Model Number:27101
- SKU:27101
Product Description
Product features:
- RS-232/422/485 3-in-1 serial interface 300-230.4 KBPS baud rate
- RS-485 conversion offers automatic data control
- Support 2, 4 wire RS-485
- All serial ports have built in 600W protection
- 10/100M Ethernet, auto detect straight/cross cable
- Support protocols like TCP/IP, UDP, DHCP
- Support standard DIN-rail, easy to install and fix
- Size (95x68x26mm)
Operating modes:
Driver operating modes
- Windows standard serial port Socket operating modes
- TCP Server operating mode
- TCP Client operating mode
- UDP operating modes
Special operating modes
- Peer connection
- Modem mode
Application fields:
- LED INFO display equipments
- PLC control and management
- SCADA, measuring instruments and monitoring system
- CNC management
- Medical treatment/medication automation
- Factory automation
- Building automation
- Check on work attendance/ Human resource management
Package includes:
- Main device 1pc
- US Plug Power adapter 1pc
- CD 1pc.
